ES-FA Analytical Balances / Electromagnetic Balances / Lab Science Balances


The ES-FA Analytical Balance is your cost-effective solution for essential laboratory weighing tasks. Designed for reliability and simplicity, this electromagnetic force restoration balance combines core functionality with practical features, making it ideal for laboratories, jewelry stores, hospitals, and chemical applications.



     Features



  • Cast aluminum housing, enhance the anti-static and anti-jamming capability
  • Stainless steel platter in round shape
  • Sliding glass wind shield oers more accurate reading
  • High precision magnetic load cell
  • Large and easy-to-read backlit LCD display
  • Leveling bubble and adjustable feet for quick set-up and stability
  • Easy-to-use buttons: ON/OFF, TARE/ZERO, PRINT/CAL, UNIT/SET, MODE/CFG
  • Functions: Weighing, Counting, Speed setting, Below hook weighing, internal calibration or external calibration
  • Bi-directional RS232 serial port, allows to communicate with computer or other device



     Dimensions



ES-FA Analytical Balance Dimensions - 210 x 376 x 348 mm

Specifications

  • Capacity / Division
    200 g x 0.001 g
    300 g x 0.001 g
    400 g x 0.001 g
    500 g x 0.001 g
    220 g x 0.0001 g
  • Units of Measure
    mg, g, oz, ct, pcs
  • Power Supply
    Power cord (Input Voltage220 V)
  • Draft shield Size
    175 x 165 x 230 mm (Inner diameter)
  • Communication
    RS232, USB (option)
  • Operating Temp
    15°C to 35°C ( 59°F to 95°F )
  • Storage Conditions
    -10°C to 60°C ( 14°F to 140°F )
    < 90 relative humidity, non-condensing
  • Pan Size
    Φ80 mm round pan
  • Packing Information
    490 x 360 x 530 mm / 1pc / ctn
    G.W.: 10kg N.W.: 9kg
  • Accessories
    RS232 cable, Below weighing hook
